Automate Your Entire Lipidic Cubic Phase Workflow

Lipidic cubic phase (LCP) is an excellent medium for the crystallization of membrane proteins and is gaining popularity in the top pharmaceutical labs worldwide. Formulatrix offers an entire suite of products that automate each phase of the LCP workflow: dispensing, screening crystallization conditions, and protein crystal imaging and identification.



Manage the entire protein crystallization experimentation process, from design and dispense to image viewing and analysis all from one software, ROCK MAKER.

ROCK MAKER is a Laboratory Information Management System (LIMS) that is there every step of the way, with powerful yet easy-to-use tools that help you get the results you need quickly.



ROCK MAKER integrates with:

NT8® - Drop Setter

FORMULATOR® - Screen Builder

MANTIS® - Liquid Handler

ROCK IMAGER® - Crystallization Imagers

SONICC® - Nanocrystal Detector

FRAP - LCP Conditions Prescreening

Reliable Drop Setting: Reduce Costs + Increase Reproducibility

  • Set up hanging drop, sitting drop, microbatch, in meso Lipidic Cubic Phase (LCP) drops, additive and seeding experiments



  • 8-tip head aspirates + dispenses drops from 25nL to 1.5 μL



  • Reusable tips give you the option to dispose tips after each dispense or reuse them to reduce costs + environmental waste



  • Proportionally-Controlled Active Humidification minimizes sample evaporation and increases experiment reproducibility



nt8 drop setter for protein crystallography

Find the optimal conditions for LCP crystal growth, without waiting on your crystals.

Prior to setting up crystallization experiments, you can quickly screen Lipidic Cubic Phase (LCP) conditions using Fluorescence Recovery After Photobleaching (FRAP).  FRAP is an optical technique that assesses how easily protein is moving about in an LCP drop. If protein is aggregated, or the LCP structure is collapsed, the protein will not diffuse and therefore never crystallize. FRAP is a great tool to accelerate crystallization methods and rule out suboptimal conditions without having to wait on the crystals actually growing.

The automated FRAP imaging system was designed specifically for performing the FRAP assay on 96-well LCP crystallization setups. The entire system is automated and user-friendly requiring a few clicks of a button to initiate a complete analysis of your plate. All of the results and analyses are integrated into FORMULATRIX' protein crystallography specific software lab management software (ROCK MAKER and ROCK IMAGER).

FRAP was developed in collaboration with Vadim Cherezov (TSRI) and the JCIMPT center led by Ray Stevens and supported by the NIH Common Fund in Structural Biology.

Crystal Clear Imaging. Unparalleled Speed.

The most trusted imager in protein crystallization - used by the top 10 pharmaceutical companies and many renowned academic centers



Screen conditions with various imaging methods - Visible Light, UV fluorescence, UV absorption, Multi-Fluorescence Imaging, Fluorescence Recovery After Photobleaching (FRAP), Second Order Nonlinear Imaging of Chiral Crystals (SONICC)



Various models to fit your budget and workflow - plate capacities from a single plate up to 940 SBS plates or 1500 LCP plates



Seamless integration with Rock Maker or your current crystallization software via Rock Imager API



Temperature regulation options available for precise temperature control from 30°C down to 4°C



Multiple plate options available - SBS, Linbro, Nextal, Terasaki/HLA and Lipid Cubic Phase (LCP) plate

Remove the guesswork.

SONICC finds crystals that other technologies cannot.

The ultimate imaging technology in visualizing protein crystals, Second Order Nonlinear Imaging of Chiral Crystals (SONICC) definitively finds crystals buried in precipitate or submicron crystals naked to the eye. Two powerful technologies, Second Harmonic Generation  (SHG) and Ultraviolet Two-Photon Excited Fluorescence (UV-TPEF) are combined together in a completely automated imager to quickly image your high throughput crystallization plates and positively identify protein crystals.

Crystals appear white against a stark black background, helping you to identify crystals even in murky environments. SONICC can detect extremely thin crystals, microcrystals <1 μm, and crystals obscured in birefringent LCP.

Major pharmaceutical and academic research labs worldwide find SONICC to be extremely successful, cost effective, and efficient.
